Quick Start Example
+ +Vs
- GND
INIT*
COM
DATA+
DATA-
Figure A-3 Grounding the INIT* terminal
3. Wait at least 7 seconds to let self-calibration and ranging
takeef- fect.
4. Configure the baud rate and/or checksum status.
5. Switch the power to the ADAM-5000 system OFF.
6. Remove the grounding on the INIT* terminal and power the
ADAM-5000 system ON.
7. Wait at least 7 seconds to let self-calibration and ranging
takeef- fect.
8. Check the settings. (If the baud rate has changed, the settings
on the host computer should be changed accordingly)
A-10 ADAM-5000
