Command Set
5050/5051/5052/5055/5056
5060/5068/5069 Digital I/O
- A 4-character value represents the output channels in
sequence from 15 thru 0 in an ADAM-5056 module.
- A 2-character value represents the output channels in
sequence from 5 thru 0 in an ADAM-5060 module.
- A 2-character value represents the output channels in
sequence from 7 thru 0 in ADAM-5055S/5068 module.
Each bit represents a channel.
(cr) is the terminating character, carriage return (0Dh)
Example command: $19S1M(cr)
response: !191322(cr)
The command asks the digital output module in slot 1 of
the ADAM-5000 system at address 19h to return the
masking status of all of its channels.
The first 2-character portion of the response indicates
the address of the ADAM-5000 system.
The second 2-characters portion of the response, value
13h (00010011), indicates that digital output channels 8,
9 and 12 are masked, while channels 10, 11, 13, 14 and 15
are valid.
The third 2-character portion of the response, value 22h
(00100010), indicates that digital output channels 1 and 5
are masked, while channels 0, 2, 3, 4, 6 and 7 are valid.
6-114 ADAM-5000
