Advantech 5000 Series - Manual (Page 250)

Module
Range
Code Input Range
Description Data
Formats
Maximum
Specified
Signal Minimum
Specified
Signal
Displayed
Resolution Actual
Value
Engineering
Units
+760.00 +000.00 0.1°C
% of FSR +100.00 +000.00 0.01% 0Eh
Type J
Thermocouple
0°C to 760°C
Two's
Complement
7FFF 0000 1 LSB
Reading/
10
Engineering
Units
+1370.0 +0000.0 0.1°C
% of FSR +100.00 +000.00 0.01% 0Fh
Type K
Thermocouple
0°C to 1370°C
Two's
Complement
7FFF 0000 1 LSB
Reading/
10
Engineering
Units
+400.00 -100.00 0.1°C
% of FSR +100.00 -025.00 0.01% 10h
Type T
Thermocouple
-100°C to
400°C
Two's
Complement
7FFF E000 1 LSB
Reading/
10
Engineering
Units
+1000.00 +0000.0 0.1°C
% of FSR +100.00 ±000.00 0.01% 11h
Type E
Thermocouple
0°C to 1000°C
Two's
Complement
7FFF 0000 1 LSB
Reading/
10
Engineering
Units
+1750.0 +0500.0 0.1°C
% of FSR +100.00 +028.57 0.01% 12h
Type R
Thermocouple
500°C to
1750°C
Two's
Complement
7FFF 2492 1 LSB
Reading/
10
Engineering
Units
+1750.0 +0500.00 0.1°C
% of FSR +100.00 +028.57 0.01% 13h
Type S
Thermocouple
500°C to
1750°C
Two's
Complement
7FFF 2492 1 LSB
Reading/
10
Engineering
Units
+1800.0 +0500.0 0.1°C
% of FSR +100.00 +027.77 0.01%
ADAM-5018
14h
Type B
Thermocouple
500°C to
1800°C
Two's
Complement
7FFF 2381 1 LSB
Reading/
10
ADAM-5000 B-5
