2-11

GF100 Series

Installation and Operation Manual
X-TMF-GF100-Series-MFC-eng
Part Number: 541B137AAG
March, 2013

Section 2 Installation

2-16 Performance Checks

This section describes how to zero and sequence the GF100 Series
devices for proper operation.

The GF100 Series must be warmed up for at least 30 minutes.

The active gas page must be correct.

The GF100 Series pressure transducer must be correctly zeroed.

The GF100 Series flow must be correctly zeroed.

This chapter describes how to zero and sequence the GF100 Series for

proper operation.

2-17 Introduction to the MultiFlo

TM

Configurator

The MutliFlo Configurator application is used to configure the gas and
range of the GF Series devices. The following section describes the
MultiFlo Configurator and its uses.

2-18 Using the MultiFlo Configurator

The MultiFlo Configurator application allows communication to GF Series
devices through personal computer with serial COM Port and a Windows
XP or Windows 7 operating system. It’s primary function is to configure
gas and flow ranges within six defined standard configurations. Flow
ranges are configured to the Nitrogen equivalent.

Using the MultiFlo Configurator software, configure the gas and flow rate
according to Table 2-3.

Table 2-3 Gas and Flow Ranges - MultiFlo Configurable - N2 Equivalent

Standard MG-MR Bin

Configurations

Flow range

Code

Gas Flow Range

(N2 Equivalent)

SH40
SH41
SH42
SH43
SH44
SH45
SH46
SH47
SH48
SH49
SH50

010C
030C
092C
280C
860C

2.6L
7.2L

015L
030L
040L
055L

3-10 sccm

11-30 sccm
31-92 sccm

93-280 sccm

281-860 sccm

861-2600 sccm

2601-7200 sccm

7201-15000 sccm

15001-30000 sccm
30001-40000 sccm
40001-55000 sccm
