28
C.
Please inspect the hardware if the current value is inconsistent with
the value in the tolerance error table below after the calibration
values of each function is changed to actual current value.
XLN3640
Function Setting Range of Transformation Value
Lo 0.1A 0 - 0.5 A
MIDL 13A 11 - 14 A
MIDH 26A 23 - 27 A
Hi 38A 34 - 39 A
XLN6024
Function Setting Range of Transformation Value
Lo 0.06A 0 - 0.5 A
MIDL 7.8A 6.6 - 9 A
MIDH 15.6A 14 - 17.2 A
Hi 22.8A 21 - 24.6 A
XLN8018
Function Setting Range of Transformation Value
Lo 0.045A 0 - 0.1 A
MIDL 5.9A 5.3 - 6.5 A
MIDH 12A 10.8 - 13.2 A
Hi 17A 15.3 - 18.7 A
CALIB CURR MIDH = 258.246 mV
CALIB CURR Hi = 377.559 mV
