PowerAgent TM SC3 Site Controller Document # 700-000014-01 Rev 2
Installation and Operation
Phoenix Broadband Technologies, LLC 10/28/2010
Page 56 of 57
The local and remote files names for the 7 Site Controller files are shown in the table below. The
Local file names may differ somewhat from the names shown depending on the version.
Local File Name Remote File Name
Firmware SC3_404.rom X2
Web files SC3_110_web1.cob WEB1
Web files SC3_110_web2.cob WEB2
Web files SC3_110_web3.cob WEB3
Web files SC3_110_web4.cob WEB4
Web files SC3_110_web5.cob WEB5
Web files SC3_110_web8.cob WEB8
TFTP uses UPD port 69. If you experience problems downloading firmware it is possible that port
69 is blocked by a firewall or router somewhere in you network. Consult with your IT department
to correct this problem.
9 Summary of Port Usage
The different features of this product use a variety of ports. The following table contains a
summary of the port utilization.
Port Protocol Usage
25 TCP SMTP – Sending email
69 UDP TFTP – Firmware updates
80 TCP HTTP – Web page
123 UDP NTP – Time server
161 UDP SNMP – Gets and Sets
162 UDP SNMP - Traps
9998 TCP Telnet – Debug port
9999 TCP Telnet – Setup
30704 UDP Java Applet – Web page real time data
It may be necessary to request the network administrator to open some of these ports, in the
firewall or router, for the associated feature to operate properly.
