RS232/RS42
2
RE MO TE
1.3 A MAX . 100 -24 0V , 50- 60H z
US
LIS TED IT2 3 I.T. E. ®
L 1 R L 2 R L 3 R L 4 R L 5 R L 6 R L 7 R L 8 R
OUTPUTS
L 1 R L 2 R L 3 R L 4 R
AD DRE SS
INPUTS
AD DRE SS
DVI-D I NPUTS
5
6
7
8
1
2
3
4
1
2
3
4
DVI-D O UTPUTS
LA N AC T LINK RESE T
INPU T
LA N
POWE R
12V
500m A
MA X
1 2 3 4
COM 3
IR 3
S G S G TX RX
4
RELA Y
3 4
COM1
TX RX RTS CT S
COM 2
IR 1
S G S G TX RX
2
RELA Y
1 2
XP A 1 002
1 2 LIM ITE R/P RO TEC T
SIG NA L OV ER TEMP
INP UT S
LO CA L O UT PU T
AU DIO
DV I-D
DTP DV I 301 Tx
PO WER 12V 0.4A MA X
DV I 20 1 T x
RS-23 2 PA SS TH RU
Tx Rx
DD C R OU TE
1
2 RE MO TE
SP AR E LO CA L
SINGLE LINK
ON 1 2
DV I 20 1 R x S ER IES
DV I-D O UTPUT
CO NT RO L PA SS -THR U Tx Rx
L R
OU TP UT S
DV I-D
AU DIO
DTP DV I 301 Rx
Extron
TLP 710MV
7" TouchLink
Touchpanel
Digital
Input
Extron
XPA 1002
Power Amplifier
TCP/IP
Network
Lighting
System
Screen
Control
Laptop
Blu-ray Player
Extron
SMX 200
Matrix Switcher
Motion
Detector
RS-232
RS-232
IR Control
to Blu-ray
Relay
Relay
Extron
IR Emitter
Extron
DTP DVI
301 Rx
Receiver
Extron
DTP DVI
301 Tx
Transmitter
Projector
Extron
IPL 250
IP Link Control
Processor
Figure 1. TLP 710MV Application Diagram
Programmable LEDs — can be user-defined to provide feedback about various system
states.
Light sensor — adjusts LCD screen backlighting to compensate for ambient lighting.
Motion sensor — When no motion is detected for a user-defined period of time, the unit
enters sleep mode to conserve power. When a user approaches the screen, the panel
detects motion and is reactivated.
Speaker — provides audible feedback in response to events triggered by the user and
audio playback for video previews.
Multiple mounting options — The TLP 710MV can be wall-mounted, rack-mounted, or
furniture-mounted.
The TLP 710TV comes with a stand that allows it to stand on a desktop or be mounted
on the optional Extron swivel mount adapter (SMA-1). If the stand is removed, the unit can
be mounted on a wall or furniture using a VESA D 75mm mount kit.
Color options — The TLP 710MV is available in black or white.
TLP 710MV and TLP 710TV • Introduction 2
