Extron Electronics TLP 710TV User Guide User Manual
Page 19
NOTE: The twisted pair cable providing the MTP (
n
) and network
o
) connections should be secured together and to both the
back panel and base using zip-ties as shown below.
LAN Connection
MTP Connection
Zip-tie
Zip-tie
Cable Runway
Figure 12.
Connecting and Securing Cables
TLP 710MV and TLP 710TV • Panel Features
13
