The GUI Configurator software is a Windows-based application. The TLP interface
is designed either by customizing an existing template or by creating an entirely new
interface. GUI Configurator offers several templates.
After the GUI has been designed on a PC, the project is saved, built, and uploaded to
the TouchLink panel to verify what it looks like on the screen. It is then imported from
the TLP unit to Global Configurator where control functions are assigned to the text and
graphic items in the layout. After assigning the control functions, the project is rebuilt and
uploaded to the controller.
The GUI Configurator and Global Configurator programs provide versatility and
adaptability for configuration and control of an AV system as it grows and evolves.

Installing the Software

Installing GUI Configurator and Global Configurator

NOTE: Use Global Configurator 3.3 or a later version and GUI Configurator 1.3 or a

later version to configure the TLP 710MV or TLP 710TV.

Insert the provided disc into the DVD drive of the computer. If the setup program does not
start automatically, run

Launch.exe

from the DVD directory in Windows

My Computer

Select the

Software

tab, locate the GUI Configurator program, and click

Install

. Follow

the on-screen instructions.
By default, the Installer program creates and places the GUI Configurator program in
the C:\Program Files\Extron\GUI Configurator folder. An icon may also be

placed on the Windows desktop.

TLP 710MV and TLP 710TV • Configuration Software
