650 MDS Section 3
Figure 2. 650 interfaced to a 6-series sonde with user-supplied GPS.
Figure 3. 650 interfaced to PC for data transfer or software upgrade.
PC Serial port
(DE-9)
You will need:
• 650
• 6115 GPS cable
• User-supplied GPS unit
with DE-9 cable
• YSI 6-series sonde with
integral or field cable
650
YSI 6-series sonde
Integral or field cable
User-supplied GPS unit
with DE-9 cable
6115 GPS cable
655174 PC Interface
Cable
650
You will need:
• 650
• YSI 655174
PC interface
cable
• PC with
active serial
port
YSI, Incorporated Drinking Water Monitoring Systems Operations Manual 3-4
