COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE 63
FC308 16 bits Frequency Status
0 None
1 Within Limit
2 Under Frequency Fail
3 Under Frequency Restore
4 Over Frequency Fail
5 Over Frequency Restore
FC309 16 bits Voltage Status
0 None
1 Within Limit
2 Under Voltage Fail
3 Under Voltage Restore
4 Over Voltage Fail
5 Over Voltage Restore
FC311 16 bits Phase Rotation Seq
0 1 Ph
1 ABC
2 ACB
3 - -
FC312 16 bits Src No Of Phases
1 Single Phase
2 Three Phase
FC313 16 bits Src Type
1 Utility
2 Generator
FC315 16 bits ATS Status In Transfer Mode
0 None
1 S1 Failed
2 S2 Failed
3 Fast Test Load Xfer
4 Fast Test No Load Xfer
5 Test Load Xfer
6 Test No Load Xfer
7 Exerciser Running
8 Exerciser Bypassed
9 Exerciser Load Test
10 Exerciser No Load
11 ATS Lockout State
12 Shunt Fault Failure
FC316 32 bits DATE MM/DD
1st byte Month 1 to 12
2nd byte Day 1 to 31
FC317 16 bits Transfer type
0 Auto
1 Manual S1 to S2, S2 to S1 (S5)
2 Manual S2 to S1 Only (S5)
Code Type Definition
