48 MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU) COMMUNICATIONS GUIDE
FC112 16 bits Communication Status
0 Error
1 OK
FC116 16 bits Switch Type
0 Open
1 Closed
FC117 16 bits Switch Type
0 Delayed
1 Closed
FC126 16 bits Disabled / Enabled Selection
0 Disabled
1 Enabled
FC130 16 bits LED Flash
Bit 0 Running
Bit 1 Stopped
Bit 2 Faulted
Bit 3 Alarm
Bit 4 Comms OK
Bit 5 Auto
Bit 6 Manual
Bit 7 USER1
Bit 8 USER2
Bit 9 USER3
Bit 10 50%
Bit 11 80%
Bit 12 100%
Bit 13 Right Top LED
Bit 14 Right Bottom LED
FC131A 16 bits Comm Fail Mode
1 Serial
2 Serial & Ethernet
8 Ethernet
FC132 16 bits Cause of Waveform/Data Log Trigger
0 None
1 Command
0xC0 VO 1
0xC1 VO 2
0xC2 VO 3
0xC3 VO 4
0xC4 VO 5
0xC5 VO 6
0xC6 VO 7
0xC7 VO 8
0xC8 VO 9
0xC9 VO 10
0xCA VO 11
0xCB VO 12
Code Type Definition
