62 MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU) COMMUNICATIONS GUIDE
28 CT Open S2 after Xfer
29 Waiting for Reset key
FC201 16 bits ATS Operating Mode
0 None
1 Normal
2 Test On Load
3 Test No Load
4 Exerciser On Load
5 Exerciser No Load
6 Fast Test
FC202 16 bits Switch Position
0 On Generator
1 On Normal Src
FC212 16 bits LCD Test Paint Color
0 None
1 Red
2 Green
3 Blue
FC300 16 bits ATS Transfer Timer
0 None
1 P1Timer
2 P2 Timer
3 W Timer
4 T Timer
5 DW Timer
6 DT Timer
7 U1 Timer
8 U2 Timer
FC301 16 bits ATS Elevetor Timer
0 None
1 W3
2 T3
FC302 16 bits Exerciser Status
0 None
1 In Progress
2 Pending
3 Bypass
4 Cancel
5 Over
FC303 16 bits Load Type
0 Gen Start And Xfer
1 Gen Start Only
FC306 16 bits R50 Status
0 No Sync Status
1 Synchronized
2 Phasing In
3 Phasing Out
Code Type Definition
