36 MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU) COMMUNICATIONS GUIDE
41352 0547 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41356 054B Reserved --- --- --- --- --- --- 1
41357 054C Timer 31 Type 0 2 1 --- FC141 0 1
41358 054D Timer 31 Pickup Delay 0 1000 1 --- F1 1 1
41359 054E Timer 31 Dropout Delay 0 1000 1 --- F1 1 1
41360 054F Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41364 0553 Reserved --- --- --- --- --- --- 1
41365 0554 Timer 32 Type 0 2 1 --- FC141 0 1
41366 0555 Timer 32 Pickup Delay 0 1000 1 --- F1 1 1
41367 0556 Timer 32 Dropout Delay 0 1000 1 --- F1 1 1
41368 0557 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41374 055D Reserved --- --- --- --- --- --- 1
CONTACT INPUT ASSIGNMENT
41375 055E Access Switch 0 57344 0 --- FC142 0 1
41376 055F Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41393 0570 Reserved --- --- --- --- --- --- 1
41394 0571 Process Interlock A 0 57344 0 --- FC142 0 1
41395 0572 Process Interlock B 0 57344 0 --- FC142 0 1
41396 0573 Process Interlock C 0 57344 0 --- FC142 0 1
41397 0574 Process Interlock D 0 57344 0 --- FC142 0 1
41398 0575 Process Interlock E 0 57344 0 --- FC142 0 1
41399 0576 Process Interlock F 0 57344 0 --- FC142 0 1
41400 0577 Process Interlock G 0 57344 0 --- FC142 0 1
41401 0578 Process Interlock H 0 57344 0 --- FC142 0 1
41402 0579 Process Interlock I 0 57344 0 --- FC142 0 1
41403 057A Process Interlock J 0 57344 0 --- FC142 0 1
41404 057B SE Limit Switch 0 57344 0 --- FC142 0 1
41405 057C SEO Limit Switch 0 57344 0 --- FC142 0 1
41406 057D SN Limit Switch 0 57344 0 --- FC142 0 1
41407 057E SNO Limit Switch 0 57344 0 --- FC142 0 1
41408 057F Disconnect Switch (DS) 0 57344 0 --- FC142 0 1
41409 0580 Test with Load (TSL/Q2) 0 57344 0 --- FC142 0 1
41410 0581 Inhibit Xfer to S2 (Q3) 0 57344 0 --- FC142 0 1
41411 0582 Inhibit Xfer to S1 (Q7) 0 57344 0 --- FC142 0 1
41412 0583 Load Shed from S2 (R15) 0 57344 0 --- FC142 0 1
41413 0584 Reserved --- --- --- --- --- --- 1
41414 0585 Engine Start (SW1) 0 57344 0 --- FC142 0 1
41415 0586 Manual X'fer S1-2, S2-1 (S12) 0 57344 0 --- FC142 0 1
41416 0587 Commit X'fer to S2 (S13) 0 57344 0 --- FC142 0 1
41417 0588 Manual X'fer S2-S1 (S5) 0 57344 0 --- FC142 0 1
41418 0589 Preferred Source Select (SW3) 0 57344 0 --- FC142 0 1
41419 058A Transition Mode Select (TMS) 0 57344 0 --- FC142 0 1
Modbus Hex Description Min Max Step Units Format Default Size in
Words
