COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE 23
32070 0815 Last Transfer Over Date --- --- --- --- F18 N/A 2
32072 0817 Last Transfer Over Time --- --- --- --- F19 N/A 2
32074 0819 Last Transfer To --- --- --- --- FC199 N/A 1
32075 081A Last Transfer From --- --- --- --- FC199 N/A 1
32076 081B Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
32079 081E Reserved --- --- --- --- --- --- 1
ATS OPERATION COUNTERS
32081 0820 Total Time On S1 --- --- --- hrs F9 N/A 2
32083 0822 Total Time On S2 --- --- --- hrs F9 N/A 2
32085 0824 Total Time Load w/o Power --- --- --- s F9 N/A 2
32087 0826 Total Transfers (S1 > S2 > S1) --- --- --- --- F1 N/A 1
32088 0827 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
32092 082B Reserved --- --- --- --- --- --- 1
ATS CONTROL
32093 082C ATS Active State --- --- --- --- FC200 N/A 1
32094 082D ATS Operating Mode --- --- --- --- FC201 N/A 1
32095 082E CT Extended Parallel Time --- --- --- cycles F1 N/A 1
32096 082F Switch Position --- --- --- --- FC202 N/A 1
32097 0830 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
32104 0837 Reserved --- --- --- --- --- --- 1
ATS EXERCISER
32105 0838 Exerciser Status --- --- --- --- FC302 N/A 1
32106 0839 Last Exerciser Date --- --- --- --- F18 N/A 2
32108 083B Last Exerciser Time --- --- --- --- F19 N/A 2
32110 083D Next Exerciser Date --- --- --- --- F18 N/A 2
32112 083F Next Exerciser Time --- --- --- --- F19 N/A 2
32114 0841 Reserved --- --- --- --- --- --- 1
32115 0842 Reserved --- --- --- --- --- --- 1
32116 0843 Reserved --- --- --- --- --- --- 1
ATS TEST
32117 0844 Reserved --- --- --- --- --- --- 1
32118 0845 Reserved --- --- --- --- --- --- 1
ATS PREFERRED SRC
32119 0846 Preferred SRC --- --- --- --- FC161 N/A 1
32120 0847 Reserved --- --- --- --- --- --- 1
ATS GEN
32121 0848 Avg. Alt Source pF --- --- --- --- F21 N/A 1
32122 0849 Avg. Alt Source kW --- --- --- kW F1 N/A 1
32123 084A Max Alt Source Current --- --- --- A F1 N/A 1
32124 084B Max Alt Source Voltage Dips --- --- --- % F2 N/A 1
32125 084C Max Alt Source Freq Dip --- --- --- Hz F2 N/A 1
32126 084D Gen Shutdown Date --- --- --- --- F18 N/A 2
32128 084F Gen Shutdown Time --- --- --- --- F19 N/A 2
Modbus Hex Description Min Max Step Units Format Default Size in
Words
