46 MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU) COMMUNICATIONS GUIDE
F26 16 bits Trace Memory Channel Data
0 Va
1 Vb
2 Vc
3 Va2
4 Vb2
5 Vc2
6 Ia
7 Ib
8 Ic
9 Ig
10 Inputs 1 to 16
11 Outputs 1 to 16
F27 32 bits UNSIGNED LONG VALUE AS MINUTES SHOW AS
LongHoursMinutes
Example: 1234 stored as 1234, and displayed as 20
F74
16 bits Data Logger Sample Rate
0 1 Cycle
1 1 Second
2 1 Minute
3 1 Hour
F75 16 bits Data Logger Status
0 Stopped
1 Started
2 Triggered
3 Pretrigger
4 PostTrigger
F77 16 bits Data Logger Channel Data
0 Disabled
1 Phase A Current
2 Phase B Current
3 Phase C Current
4 Average Phase Current
5 Current THD
6 Current Unbalance
7 Neutral Current
8 System Frequency
9 Vab
10 Vbc
11 Vca
12 Van
13 Vbn
14 Vcn
15 Power Factor
16 Real Power (kW)
17 Reactive Power (kvar)
18 Apparent Power (kVA)
Code Type Definition
