32 MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU) COMMUNICATIONS GUIDE
41111 0456 MCC Setpoint Access 0 1 1 --- FC126 1 1
41112 0457 Passcode Entry 0 55555 1 --- F1 0 1
41113 0458 Reserved --- --- --- --- --- --- 1
41114 0459 Reserved --- --- --- --- --- --- 1
41115 045A Reserved --- --- --- --- --- --- 1
41116 045B Reserved --- --- --- --- --- --- 1
FLEXLOGIC TIMERS
41117 045C Timer 1 Type 0 2 1 --- FC141 0 1
41118 045D Timer 1 Pickup Delay 0 1000 1 --- F1 1 1
41119 045E Timer 1 Dropout Delay 0 1000 1 --- F1 1 1
41120 045F Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41124 0463 Reserved --- --- --- --- --- --- 1
41125 0464 Timer 2 Type 0 2 1 --- FC141 0 1
41126 0465 Timer 2 Pickup Delay 0 1000 1 --- F1 1 1
41127 0466 Timer 2 Dropout Delay 0 1000 1 --- F1 1 1
41128 0467 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41132 046B Reserved --- --- --- --- --- --- 1
41133 046C Timer 3 Type 0 2 1 --- FC141 0 1
41134 046D Timer 3 Pickup Delay 0 1000 1 --- F1 1 1
41135 046E Timer 3 Dropout Delay 0 1000 1 --- F1 1 1
41136 046F Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41140 0473 Reserved --- --- --- --- --- --- 1
41141 0474 Timer 4 Type 0 2 1 --- FC141 0 1
41142 0475 Timer 4 Pickup Delay 0 1000 1 --- F1 1 1
41143 0476 Timer 4 Dropout Delay 0 1000 1 --- F1 1 1
41144 0477 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41148 047B Reserved --- --- --- --- --- --- 1
41149 047C Timer 5 Type 0 2 1 --- FC141 0 1
41150 047D Timer 5 Pickup Delay 0 1000 1 --- F1 1 1
41151 047E Timer 5 Dropout Delay 0 1000 1 --- F1 1 1
41152 047F Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41156 0483 Reserved --- --- --- --- --- --- 1
41157 0484 Timer 6 Type 0 2 1 --- FC141 0 1
41158 0485 Timer 6 Pickup Delay 0 1000 1 --- F1 1 1
41159 0486 Timer 6 Dropout Delay 0 1000 1 --- F1 1 1
41160 0487 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41164 048B Reserved --- --- --- --- --- --- 1
41165 048C Timer 7 Type 0 2 1 --- FC141 0 1
41166 048D Timer 7 Pickup Delay 0 1000 1 --- F1 1 1
41167 048E Timer 7 Dropout Delay 0 1000 1 --- F1 1 1
Modbus Hex Description Min Max Step Units Format Default Size in
Words
