38
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU)
COMMUNICATIONS GUIDE
41697
06A0
Flex Equation
0
65535
1
---
FC142
1024
512
42209
08A0
Reserved
---
---
---
---
---
---
1
to
to
Reserved
---
---
---
---
---
---
1
43118
0C2D
Reserved
---
---
---
---
---
---
2
ATS
43119
0C2E
Switch Option
0
2
1
---
FC325
1
1
43120
0C2F
Auto / Manual Select
0
3
1
---
FC317
0
1
43121
0C30
Load Control 1 (LC1) Type
0
2
1
---
FC319
0
1
43122
0C31
Load Control 2 (LC2) Type
0
2
1
---
FC319
0
1
43123
0C32
Load Control 3 (LC3) Type
0
2
1
---
FC319
0
1
43124
0C33
Load Control 4 (LC4) Type
0
2
1
---
FC319
0
1
43125
0C34
Load Control 5 (LC5) Type
0
2
1
---
FC319
0
1
43126
0C35
Load Control 6 (LC6) Type
0
2
1
---
FC319
0
1
43127
0C36
Reserved
---
---
---
---
---
---
1
to
to
Reserved
---
---
---
---
---
---
1
43133
0C3C
Reserved
---
---
---
---
---
---
1
43134
0C3D
R15
0
1
0
---
FC329
0
1
43135
0C3E
ATS Amps
0
16
1
A
FC165
0
1
43136
0C3F
CTAP
0
1
1
---
FC103
0
1
43137
0C40
ATS Name
0
10
1
---
F22
22
10
43147
0C4A
ATS Number of Poles
0
2
1
---
FC197
0
1
43148
0C4B
ATS Type
0
7
1
---
FC159
0
1
43149
0C4C
ATS Voltage
0
13
1
V
FC166
0
1
43150
0C4D
S1 Number of Phases
1
2
1
---
FC312
0
1
43151
0C4E
S1 Type
1
2
1
---
FC313
0
1
43152
0C4F
S2 Number of Phases
1
2
1
---
FC312
0
1
43153
0C50
S2 Type
1
2
1
---
FC313
0
1
43154
0C51
Solenoid Pulse
0
1500
1
ms
F1
500
1
43155
0C52
Reserved
---
---
---
---
---
---
1
43156
0C53
Coil Control Delay Timer Value 0
3600
1
---
F24
0
1
43157
0C54
CT Parallel Timer Value
0
20
1
10ms
F1
0
1
43158
0C55
Reserved
---
---
---
---
---
---
1
43159
0C56
Open Last Close Time (OLC)
0
3600
1
---
F24
100
1
43160
0C57
Sol Saver Time Value
1
3600
1
---
F24
3
1
43161
0C58
Source Qualification Time
1
3600
1
---
F24
20
1
43162
0C59
Sync. Timer Value
0
3600
1
---
F24
10
1
43163
0C5A
CT Voltage Differential Limit
0
10
1
%
F1
5
1
43164
0C5B
Reserved
---
---
---
---
---
---
1
43165
0C5C
Reserved
---
---
---
---
---
---
1
43166
0C5D
Reserved
---
---
---
---
---
---
1
43167
0C5E
Reserved
---
---
---
---
---
---
1
ATS CONTROL
43168
0C5F
Preferred Source
0
1
1
---
FC161
0
1
43169
0C60
Commit X'fer to S2 (S13)
0
1
1
---
FC126
0
1
43170
0C61
Transition Mode Select
0
1
1
---
FC117
0
1
43171
0C62
Auto Mode Shed Mode
0
1
1
---
FC326
1
1
Modbus
Hex
Description
Min
Max
Step
Units
Format Default
Size in
Words
