COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE 43
43437 0D6C Reserved --- --- --- --- --- --- 1
43438 0D6D CDT Event 22 Date 0 0X0C1F082E 1 --- FC316 0 2
43440 0D6F CDT Event 22 Load 0 1 1 --- FC303 0 1
43441 0D70 CDT Event 23 Start Time 0 0X173B3B63 1 --- F19 0 2
43443 0D72 CDT Event 23 Duration 0 3600 1 --- F24 0 1
43444 0D73 Reserved --- --- --- --- --- --- 1
43445 0D74 CDT Event 23 Date 0 0X0C1F082E 1 --- FC316 0 2
43447 0D76 CDT Event 23 Load 0 1 1 --- FC303 0 1
43448 0D77 CDT Event 24 Start Time 0 0X173B3B63 1 --- F19 0 2
43450 0D79 CDT Event 24 Duration 0 3600 1 --- F24 0 1
43451 0D7A Reserved --- --- --- --- --- --- 1
43452 0D7B CDT Event 24 Date 0 0X0C1F082E 1 --- FC316 0 2
43454 0D7D CDT Event 24 Load 0 1 1 --- FC303 0 1
43455 0D7E Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
43462 0D85 Reserved --- --- --- --- --- --- 1
ANALOG ALARM SETTINGS
43463 0D86 Voltage THD Alarm Level 1 1001 1 % F2* 1001 1
43464 0D87 Voltage THD Alarm Delay 0 65535 1 s F1 0 1
43465 0D88 Current THD Alarm Level 1 1001 1 % F2* 1001 1
43466 0D89 Current THD Alarm Delay 0 65535 1 s F1 0 1
43467 0D8A Low PF Lag Alarm Level 0 100 1 --- F3* 100 1
43468 0D8B Low PF Alarm Delay 0 65535 1 s F1 0 1
43469 0D8C Overpower Alarm Level 1 50001 1 kW F2* 50001 1
43470 0D8D Overpower Alarm Delay 0 65535 1 s F1 0 1
43471 0D8E Phase A Overcurrent Level 1 201 1 %FLA F1* 201 1
43472 0D8F Phase A Overcurrent Delay 0 65535 1 s F1 0 1
43473 0D90 Phase B Overcurrent Level 1 201 1 %FLA F1* 201 1
43474 0D91 Phase B Overcurrent Delay 0 65535 1 s F1 0 1
43475 0D92 Phase C Overcurrent Level 1 201 1 %FLA F1* 201 1
43476 0D93 Phase C Overcurrent Delay 0 65535 1 s F1 0 1
43477 0D94 Neutral Overcurrent Level 1 201 1 %FLA F1* 201 1
43478 0D95 Neutral Overcurrent Delay 0 65535 1 s F1 0 1
43479 0D96 Low PF Lead Alarm Level 0 100 1 --- F3 * 100 1
*Maximum setpoint values represent OFF.
Modbus Hex Description Min Max Step Units Format Default Size in
Words
