MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU)
COMMUNICATIONS GUIDE
32130
0851
Time To ShutDown Gen
---
---
---
---
F24
N/A
1
32131
0852
Date Gen Start Sent
---
---
---
---
F18
N/A
2
32133
0854
Time Gen Start Sent
---
---
---
---
F19
N/A
2
32135
0856
Date Gen Stop Sent
---
---
---
---
F18
N/A
2
32137
0858
Time Gen Start Stop
---
---
---
---
F19
N/A
2
32139
085A
Gen Supply OK Date
---
---
---
---
F18
N/A
2
32141
085C
Gen Supply OK Time
---
---
---
---
F19
N/A
2
32143
085E
Alt Source Startup Time
---
---
---
s
F1
N/A
1
32144
085F
Max Alt Source Volt THD
---
---
---
%
F1
N/A
1
32145
0860
Time Gen Start Removed
---
---
---
---
F19
N/A
2
32147
0862
Reserved
---
---
---
---
---
---
1
ATS R50
32148
0863
In Phase Monitor Status
---
---
---
---
FC306
N/A
1
32149
0864
Reserved
---
---
---
---
---
---
1
32150
0865
S1 S2 Phase A Difference
---
---
---
°
F16
N/A
1
32151
0866
Reserved
---
---
---
---
---
---
1
32152
0867
Reserved
---
---
---
---
---
---
1
32153
0868
Reserved
---
---
---
---
---
---
2
32155
086A
Reserved
---
---
---
---
---
---
1
32156
086B
Reserved
---
---
---
---
---
---
1
32157
086C
Reserved
---
---
---
---
---
---
1
32158
086D
Reserved
---
---
---
---
---
---
1
ATS S1 COUNTERS
32159
086E
Total Primary Source Failures
---
---
---
---
F1
N/A
1
32160
086F
S1 Accum. Avail.
---
---
---
hrs
F9
N/A
2
32162
0871
S1 Accum. Unavail.
---
---
---
hrs
F9
N/A
2
32164
0873
S1 Avail. Since Last Restore
---
---
---
hrs
F9
N/A
2
32166
0875
S1 Last Unavail. Time
---
---
---
hrs
F9
N/A
2
32168
0877
Last Primary Source Fail Date
---
---
---
---
F18
N/A
2
32170
0879
Last Primary Source Fail Time ---
---
---
---
F19
N/A
2
32172
087B
S1 Date Stamp Last Restore
---
---
---
---
F18
N/A
2
32174
087D
Time Primary Ret (or Test
Reset)
---
---
---
---
F19
N/A
2
32176
087F
Last Transfer to S1 Date
---
---
---
---
F18
N/A
2
32178
0881
Last Transfer to S1 Time
---
---
---
---
F19
N/A
2
32180
0883
Reserved
---
---
---
---
---
---
1
32181
0884
Reserved
---
---
---
---
---
---
1
ATS S2 COUNTERS
32182
0885
Number of S2 Failures
---
---
---
---
F1
N/A
1
32183
0886
S2 Accum. Avail.
---
---
---
hrs
F9
N/A
2
32185
0888
S2 Accum. Unavail.
---
---
---
hrs
F9
N/A
2
32187
088A
S2 Avail. Since Last Restore
---
---
---
hrs
F9
N/A
2
32189
088C
S2 Last Unavail. Time
---
---
---
hrs
F9
N/A
2
32191
088E
S2 Date Stamp Last Fail
---
---
---
---
F18
N/A
2
32193
0890
S2 Time Stamp Last Fail
---
---
---
---
F19
N/A
2
32195
0892
S2 Date Stamp Last Restore
---
---
---
---
F18
N/A
2
Modbus
Hex
Description
Min
Max
Step
Units
Format Default
Size in
Words
