26 MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU) COMMUNICATIONS GUIDE
32254 08CD VI Timer Countdown --- --- --- --- F24 N/A 1
32255 08CE W Timer Countdown --- --- --- --- F24 N/A 1
LOAD CONTROL TIMERS
32256 08CF Pre LC1 Timer Countdown --- --- --- --- F24 N/A 1
32257 08D0 Pre LC2 Timer Countdown --- --- --- --- F24 N/A 1
32258 08D1 Pre LC3 Timer Countdown --- --- --- --- F24 N/A 1
32259 08D2 Pre LC4 Timer Countdown --- --- --- --- F24 N/A 1
32260 08D3 Pre LC5 Timer Countdown --- --- --- --- F24 N/A 1
32261 08D4 Pre LC6 Timer Countdown --- --- --- --- F24 N/A 1
32262 08D5 Post LC1 Timer Countdown --- --- --- --- F24 N/A 1
32263 08D6 Post LC2 Timer Countdown --- --- --- --- F24 N/A 1
32264 08D7 Post LC3 Timer Countdown --- --- --- --- F24 N/A 1
32265 08D8 Post LC4 Timer Countdown --- --- --- --- F24 N/A 1
32266 08D9 Post LC5 Timer Countdown --- --- --- --- F24 N/A 1
32267 08DA Post LC6 Timer Countdown --- --- --- --- F24 N/A 1
32268 08DB Reserved --- --- --- --- --- --- 1
32269 08DC Reserved --- --- --- --- --- --- 1
32270 08DD Reserved --- --- --- --- --- --- 1
32271 08DE Reserved --- --- --- --- --- --- 1
32272 08DF Reserved --- --- --- --- --- --- 1
SETPOINTS
COMMANDS
40001 0000 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
40128 007F Reserved --- --- --- --- --- --- 1
40129 0080 Command address 0 65535 0 --- F1 0 1
40130 0081 Command Function 0 65535 0 --- F1 0 1
40131 0082 Command Data 1 0 65535 0 --- F1 0 1
40132 0083 Command Data 2 0 65535 0 --- F1 0 1
40133 0084 Command Data 3 0 65535 0 --- F1 0 1
40134 0085 Command Data 4 0 65535 0 --- F1 0 1
40135 0086 Command Data 5 0 65535 0 --- F1 0 1
40136 0087 Command Data 6 0 65535 0 --- F1 0 1
40137 0088 Command Data 7 0 65535 0 --- F1 0 1
40138 0089 Command Data 8 0 65535 0 --- F1 0 1
40139 008A Command Data 9 0 65535 0 --- F1 0 1
40140 008B Command Data 10 0 65535 0 --- F1 0 1
40141 008C Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
40171 00AA Reserved --- --- --- --- --- --- 1
COMMUNICATION SETTINGS
40172 00AB Slave Address 1 254 1 --- F1 254 1
40173 00AC RS485 Baud Rate 0 4 1 --- FC101 4 1
40174 00AD Reserved --- --- --- --- --- --- 1
Modbus Hex Description Min Max Step Units Format Default Size in
Words
