COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE 31
40674 02A1 Trace Memory Sample Index 0 2048 1 --- F1 0 1
40675 02A2 Trigger Source 1 40964 1 --- FC132 1 1
40676 02A3 Trigger Position 0 100 1 % F1 0 1
40677 02A4 Trigger Mode 0 1 1 --- FC148 0 1
40678 02A5 Reserved --- --- --- --- --- --- 1
DATA LOGGER
40679 02A6 Data Log Number Selector 0 65535 1 --- F1 0 1
40680 02A7 Data Log Channel Selector -32767 32767 1 --- F4 0 1
40681 02A8 Data Log Sample Selector
(DLSS)
-32767 32767 1 --- F4 0 1
40682 02A9 Sample Rate 0 3 1 --- F74 1 1
40683 02AA Continuous Mode 0 1 1 --- FC126 0 1
40684 02AB Buffer Organization 0 1 1 --- F1 0 1
40685 02AC Trigger Position 0 100 1 % F1 25 1
40686 02AD Trigger Source 0 40962 1 --- FC132 0 1
40687 02AE Channel 1 Source 0 26 1 --- F77 1 1
40688 02AF Channel 2 Source 0 26 1 --- F77 2 1
40689 02B0 Channel 3 Source 0 26 1 --- F77 3 1
40690 02B1 Channel 4 Source 0 26 1 --- F77 0 1
40691 02B2 Channel 5 Source 0 26 1 --- F77 0 1
40692 02B3 Channel 6 Source 0 26 1 --- F77 0 1
40693 02B4 Channel 7 Source 0 26 1 --- F77 0 1
40694 02B5 Channel 8 Source 0 26 1 --- F77 0 1
40695 02B6 Channel 9 Source 0 26 1 --- F77 0 1
40696 02B7 Channel 10 Source 0 26 1 --- F77 0 1
40697 02B8 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
40856 0357 Reserved --- --- --- --- --- --- 1
CURRENT UNBALANCE (REQUIRED=IO_A)
40857 0358 Current Unbalance Alarm Level 4 41 1 % F1* 15 1
40858 0359 Current Unbalance Alarm
Delay
1 60 1 s F1 1 1
40859 035A Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41039 040E Reserved --- --- --- --- --- --- 1
CALIBRATION
41040 040F Calibration Date 0 0X0C1F082E 1 --- F18 0 2
41042 0411 Calibration Time 0 0X173B3B63 1 --- F19 0 2
41044 0413 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
41105 0450 Reserved 1
SECURITY
41106 0451 Passcode Level 1 11111 55556 1 --- F1* 11111 1
41107 0452 Passcode Level 2 11111 55556 1 --- F1* 22222 1
41108 0453 Reserved --- --- --- --- --- --- 1
41109 0454 Access Switch Level 1 3 1 --- F1 1 1
41110 0455 Comms Security 0 1 1 --- FC126 0 1
Modbus Hex Description Min Max Step Units Format Default Size in
Words
