COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU)
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE
27
to
to
Reserved
---
---
---
---
---
---
1
40180
00B3
Reserved
---
---
---
---
---
---
1
40181
00B4
NTP IP Address
0
0xFFFFFFFF 1
---
FC150
0
2
40183
00B6
Ethernet IP address
0
0xFFFFFFFF 1
---
FC150
0
2
40185
00B8
Ethernet subnet mask
0
0xFFFFFFFF 1
---
FC150
0xFFFFFC00
2
40187
00BA
Ethernet gateway address
0
0xFFFFFFFF 1
---
FC150
0
2
40189
00BC
Reserved
---
---
---
---
---
---
1
to
to
Reserved
---
---
---
---
---
---
1
40227
00E2
Reserved
---
---
---
---
---
---
1
REAL-TIME CLOCK/DAYLIGHT SAVINGS
40228
00E3
Set Date
0
0x0C1F082E 0
---
F18
0
2
40230
00E5
Set Time
0
0x173B3B63 0
---
F19
0
2
40232
00E7
Time Offset From UTC
-2400
2400
25
hrs
F6
0
1
40233
00E8
Reserved
---
---
---
---
---
---
1
40234
00E9
Daylight Savings
0
1
1
---
FC126
0
1
40235
00EA
DST Start Month
0
12
1
---
FC169
0
1
40236
00EB
DST Start Week
0
5
1
---
FC170
0
1
40237
00EC
DST Start Weekday
0
7
1
---
FC171
0
1
40238
00ED
DST End Month
0
12
1
---
FC169
0
1
40239
00EE
DST End Week
0
5
1
---
FC170
0
1
40240
00EF
DST End Weekday
0
7
1
---
FC171
0
1
40241
00F0
Time (broadcast)
0
389757795
0
---
F19
0
2
40243
00F2
Date (broadcast)
0
203360302
0
---
F18
0
2
40245
00F4
Reserved
---
---
---
---
---
---
1
to
to
Reserved
---
---
---
---
---
---
1
40261
0104
Reserved
---
---
---
---
---
---
1
VIRTUAL INPUT
40262
0105
Virtual Input 32-1 (Bit Field)
0
0xFFFFFFFF 1
---
FC167
0
2
40264
0107
Reserved
---
---
---
---
---
---
1
40265
0108
Reserved
---
---
---
---
---
---
1
CURRENT SENSING
40266
0109
Phase CT Type
0
2
1
---
FC105
0
1
40267
010A
CT Primary
40
1000
1
A
F1
40
1
40268
010B
Ground CT Type
0
2
1
---
FC104
1
1
40269
010C
Reserved
---
---
---
---
---
---
1
40270
010D
CT Primary Turns
1
10
1
---
F1
1
1
40271
010E
Reserved
---
---
---
---
---
---
1
to
to
Reserved
---
---
---
---
---
---
1
40275
0112
Reserved
---
---
---
---
---
---
1
VOLTAGE SENSING
40276
0113
3 Phase Voltage Connection
0
1
1
---
FC106
0
1
40277
0114
Aux VT Connection
0
8
1
---
FC176
0
1
40278
0115
Aux VT Primary
110
690
1
V
F1
415
1
40279
0116
Aux VT Secondary
110
300
1
V
F1
110
1
40280
0117
3-phase Voltage Connect. S2
0
1
1
---
FC106
0
1
40281
0118
Reserved
---
---
---
---
---
---
1
Modbus
Hex
Description
Min
Max
Step
Units
Format Default
Size in
Words
