COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE 17
POWER METERING
30384 017F Power Factor --- --- --- --- F21 N/A 1
30385 0180 Real Power --- --- --- kW F13 N/A 2
30387 0182 Reserved --- --- --- --- --- --- 1
30388 0183 Reserved --- --- --- --- --- --- 1
30389 0184 Reactive Power --- --- --- kvar F13 N/A 2
30391 0186 Apparent Power --- --- --- kVA F2 N/A 1
30392 0187 MWh Consumption --- --- --- MWh F17 N/A 2
30394 0189 Mvarh Consumption --- --- --- Mvarh F17 N/A 2
30396 018B Reserved --- --- --- --- --- --- 2
30398 018D Apparent Power --- --- --- kVA F10 N/A 2
30400 018F Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
30504 01F7 Reserved --- --- --- --- --- --- 1
LED STATUS FOR GRAPHICAL AND BASIC CONTROL PANEL
30505 01F8 LED Status --- --- --- --- FC144 N/A 2
30507 01FA Reserved --- --- --- --- --- --- 1
30508 01FB Reserved --- --- --- --- --- --- 1
GCP FACTORY TEST
30509 01FC LCD Test Color --- --- --- --- FC212 N/A 1
30510 01FD Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
30523 020A Reserved --- --- --- --- --- --- 1
USER MAP VALUES
30524 020B User Map Value 1 --- --- --- --- F1 N/A 1
30525 020C User Map Value 2 --- --- --- --- F1 N/A 1
30526 020D User Map Value 3 --- --- --- --- F1 N/A 1
30527 020E User Map Value 4 --- --- --- --- F1 N/A 1
to to Reserved --- --- --- --- --- --- 1
30645 0284 User Map Value 122 --- --- --- --- F1 N/A 1
30646 0285 User Map Value 123 --- --- --- --- F1 N/A 1
30647 0286 User Map Value 124 --- --- --- --- F1 N/A 1
30648 0287 User Map Value 125 --- --- --- --- F1 N/A 1
30649 0288 Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
30656 028F Reserved --- --- --- --- --- --- 1
SELF TEST
30657 0290 Internal Fault Cause --- --- --- --- FC188 N/A 2
EVENT RECORDER
30659 0292 Event Recorder Last Reset 2
words
--- --- --- --- F18 N/A 2
30661 0294 Total Number of Events Since
Last Clear
--- --- --- --- F1 N/A 1
30662 0295 Cause --- --- --- --- FC134 N/A 1
30663 0296 Load On --- --- --- --- FC202 N/A 1
30664 0297 Time --- --- --- --- F19 N/A 2
30666 0299 Date --- --- --- --- F18 N/A 2
Modbus Hex Description Min Max Step Units Format Default Size in
Words
