COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE 9
Operation Code Description
1 Reset
96 Clear Last Fault Data Prompt
97 Reset MWh and Mvarh Meters
99 Clear Trip Counters
100 Clear Event Records
102 Clear Maintenance Timer
120 Trigger Waveform Capture
161 Reload Factory Setpoints 2
162 Reload Factory Setpoints 1
163 Restore to setpoint acess only
181 MX350 Test
182 MX350 Test - Fast Test
183 MX350 Test - Xfer Load
184 MX350 Test - No Xfer
185 MX350 Test - Bypass Exerciser
186 MX350 Test - Cancel Exerciser Bypass
188 MX350 Test - Cancel Bypass
189 MX350 Message - Bypass
190 MX350 Message - Yes
191 MX350 Message - No
192 MX350 Message - Escape
193 MX350 Message - Cancel
194 MX350 Message - Silence
195 MX350 Message - Reset
The following commands can only be performed using function code 05H
196
Reset Time S2 Available Counter
197 Alarm Silence
198 Control to bypass W-timer
199 Control to bypass T-timer
200 Net Ctrl Test on No load
201 Fast Load Test Control
202 Regular Load Test Control
203 Auto/Manual retransfer to S1
204 Auto/Manual transfer to S1/S2
205 Net Ctrl Load Shed for S1
206 Net Ctrl Inhibit Transfer to S2
207 Net Ctrl Inhibit Transfer to S1
208 Net Ctrl Transition Mode Selector
209 Command to Bypass R50
210 Confirm Bypass R50
211 Cancel Bypass R50
223 Net Ctrl Test on Load
224 Net Ctrl Transfer Commit
