COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – COMMUNICATIONS GUIDE 19
30859 035A Reserved --- --- --- --- --- --- 1
DATA LOG INFORMATION
30860 035B # of Triggers Since Clear --- --- --- --- F4 N/A 1
30861 035C # of Data Log Samples Stored --- --- --- --- F4 N/A 1
30862 035D Data Log Start Index --- --- --- --- F4 N/A 1
30863 035E Data Log Trigger Index --- --- --- --- F4 N/A 1
30864 035F Trigger Cause --- --- --- --- FC133 N/A 1
30865 0360 Trigger Date --- --- --- --- F18 N/A 2
30867 036A Trigger Time --- --- --- --- F19 N/A 2
30869 036B Data Log Status --- --- --- --- F75 N/A 1
30870 036C Reserved --- --- --- --- --- --- 1
to to Reserved --- --- --- --- --- --- 1
30951 03B6 Reserved --- --- --- --- --- --- 1
STATUS BUFFER
30952 03B7 Alarm Status 4 --- --- --- --- FC182 N/A 2
30954 03B9 Alarm Status 3 --- --- --- --- FC181 N/A 2
30956 03BB Alarm Status 2 --- --- --- --- FC180 N/A 2
30958 03BD Alarm Status 1 --- --- --- --- FC179 N/A 2
30960 03BF Trip Status 4 --- --- --- --- FC186 N/A 2
30962 03C1 Trip Status 3 --- --- --- --- FC185 N/A 2
30964 03C3 Trip Status 2 --- --- --- --- FC184 N/A 2
30966 03C5 Trip Status 1 --- --- --- --- FC183 N/A 2
30968 03C7 Message Status 4 --- --- --- --- FC190 N/A 2
30970 03C9 Message Status 3 --- --- --- --- FC189 N/A 2
30972 03CB Message Status 2 --- --- --- --- FC188 N/A 2
30974 03CD Message Status 1 --- --- --- --- FC187 N/A 2
30976 03CF Ctrl Element Status 4 --- --- --- --- FC194 N/A 2
30978 03D1 Ctrl Element Status 3 --- --- --- --- FC193 N/A 2
30980 03D3 Ctrl Element Status 2 --- --- --- --- FC192 N/A 2
30982 03D5 Ctrl Element Status 1 --- --- --- --- FC191 N/A 2
30984 03D7 Reserved --- --- --- --- --- --- 1
30985 03D8 Reserved --- --- --- --- --- --- 1
30986 03D9 Reserved --- --- --- --- --- --- 1
FLEXLOGIC
30987 03DA Element Flag --- --- --- --- FC145 N/A 384
31371 055A Program Status --- --- --- --- FC109 N/A 1
31372 055B Flex Lines Used --- --- --- --- F1 N/A 1
31373 055C Error Line --- --- --- --- F1 N/A 1
31374 055D Reserved --- --- --- --- --- --- 1
31375 055E Reserved --- --- --- --- --- --- 1
31376 055F Reserved --- --- --- --- --- --- 1
31377 0560 Reserved --- --- --- --- --- --- 1
COMMUNICATION
31378 0561 Serial Status --- --- --- --- FC112 N/A 1
31379 0562 Ethernet Status --- --- --- --- FC112 N/A 1
31380 0563 Reserved --- --- --- --- --- --- 1
Modbus Hex Description Min Max Step Units Format Default Size in
Words
