DS2180A

041995 4/36

POWER AND TEST PIN DESCRIPTION (40–PIN DIP ONLY) Table 3

PIN

SYMBOL

TYPE

DESCRIPTION

20

V

SS

Signal Ground. 0.0 volts.

32

TEST

I

Test Mode. Tie to V

SS

for normal operation.

40

V

DD

Positive Supply. 5.0 volts.

RECEIVE PIN DESCRIPTION (40–PIN DIP ONLY) Table 4

PIN

SYMBOL

TYPE

DESCRIPTION

21

RYEL

O

Receive Yellow Alarm. Transitions high when yellow alarm detected, goes
low when alarm clears.

22

RLINK

O

Receive Link Data. Updated with extracted FDL data one RCLK before start
of odd frames (193E) and held until next update. Updated with extracted S-bit
data one RCLK before start of even frames (193S) and held until next update.

23

RLCLK

O

Receive Link Clock. 4 KHz demand clock for RLINK.

24

RCLK

I

Receive Clock. 1.544 MHz primary clock.

25

RCHCLK

O

Receive Channel Clock. 192 KHz clock identifies time slot (channel) bound-
aries.

26

RSER

O

Receive Serial Data. Received NRZ serial data, updated on rising edges of
RCLK.

27

RFSYNC

O

Receive Frame Sync. Extracted 8 KHz clock, one RCLK wide, indicates F-
Bit position in each frame.

28

RMSYNC

O

Receive Multiframe Sync. Extracted multiframe sync; edge indicates start
of multiframe, 50% duty cycle.

29

RABCD

O

Receive ABCD Signaling. Extracted signaling data output, valid for each
channel time in signaling frames. In non-signaling frames, RABCD outputs
the LSB of each channel word.

30

RSIGFR

O

Receive Signaling Frame. High during signaling frames, low during resync
and non-signaling frames.

31

RSIGSEL

O

Receive Signaling Select. In 193E framing a .667 KHz clock which identi-
fies signaling frames A and C. A 1.33 KHz clock in 193S.

33

RST

I

Reset. A high-low transition clears all internal registers and resets receive
side counters. A high-low-high transition will initiate a receive resync.

34
35

RPOS
RNEG

I

Receive Bipolar Data Inputs. Samples on falling edge of RCLK. Tie togeth-
er to receive NRZ data and disable bipolar violation monitoring circuitry.

36

RCL

O

Receive Carrier Loss. High if 32 consecutive 0’s appear at RPOS and
RNEG; goes low after next 1.

37

RBV

O

Receive Bipolar Violation. High during accused bit time at RSER if bipolar
violation detected, low otherwise.

38

RFER

O

Receive Frame Error. High during F-Bit time when F

T

or F

S

errors occur

(193S) or when FPS or CRC errors occur (193E). Low during resync.

39

RLOS

O

Receive Loss of Sync. Indicates sync status; high when internal resync is
in progress, low otherwise.
