Preliminary W79E8213/W79E8213R Data Sheet
Publication Release Date: July 11, 2008
- 90 - Revision A2
26. ELECTRICAL CHARACTERISTICS
26.1 Absolute Maximum Ratings
PARAMETER SYMBOL MIN MAX UNIT
DC Power Supply VDD
−VSS -0.3 +7.0 V
Input Voltage VIN VSS-0.3 VDD+0.3 V
Operating Temperature TA -40 +85 °C
Storage Temperature Tst -55 +150 °C
P1 Sink current ISK - 90 mA
Note: Exposure to conditions beyond those listed under absolute maximum ratings may adversely affects the lift and reliability
of the device.
26.2 DC ELECTRICAL CHARACTERISTICS
(TA = -40~85
°C, unless otherwise specified.)
SPECIFICATION
PARAMETER SYM.
MIN. TYP. MAX. UNIT
TEST CONDITIONS
V
DD1
2.4 - 5.5
V
DD
=4.5V ~ 5.5V @ 20MHz
V
DD
=2.7V ~ 5.5V @ 12MHz
V
DD
=2.4V ~ 5.5V @ 4MHz Operating Voltage
V
DD2
3.0 - 5.5
V
NVM program and erase
operation.
I
DD1
- 8.30 12
No load, /RST = VSS, V
DD
=
5.0V @ 20MHz
I
DD2
- 4.20 6
No load, /RST = VSS, V
DD
=
3.0V @ 20MHz
I
DD3
- 14.50 20
No load, /RST = V
DD
, V
DD
=
5.0V @ 20MHz, RUN NOP
Operating Current (20MHz)
I
DD4
- 5.20 7
mA
No load, /RST = V
DD
, V
DD
=
3.0V @ 20MHz, RUN NOP
I
DD5
- 3.60 5
No load, /RST = VSS, V
DD
=
5.0V @ 4MHz
I
DD6
- 1.86 3
No load, /RST = VSS, V
DD
=
3.0V @ 4MHz
I
DD7
- 8.60 12
No load, /RST = V
DD
, V
DD
=
5.0V @ 4MHz, RUN NOP
Operating Current (4MHz)
I
DD8
- 2.20 3.5
mA
No load, /RST = V
DD
, V
DD
=
3.0V @ 4MHz, RUN NOP
I
IDLE1
- 5.70 8
No load, V
DD
= 5.0V
@ 20MHz
Idle Current
I
IDLE2
- 2.48 3.5
mA
No load, V
DD
= 3.0V
@ 20MHz
