13. PROGRAMMABLE TIMERS/COUNTERS
The W79E8213 series have two 16-bit programmable timer/counters and one programmable
Watchdog Timer. The Watchdog Timer is operationally quite different from the other two timers. Its’
timer/counters have additional timer 0 or timer 1 overflow toggle output enable feature as compare to
conventional timer/counters. This timer overflow toggle output can be configured to automatically
toggle T0 or T1 pin output whenever a timer overflow occurs.
13.1 Timer/Counters 0 & 1
The W79E8213 series have two 16-bit Timer/Counters. Each of these Timer/Counters has two 8 bit
registers which form the 16 bit counting register. For Timer/Counter 0 they are TH0, the upper 8 bits
register, and TL0, the lower 8 bit register. Similarly Timer/Counter 1 has two 8 bit registers, TH1 and
TL1. The two can be configured to operate either as timers, counting machine cycles or as counters
counting external inputs.
When configured as a "Timer", the timer counts clock cycles. The timer clock can be programmed to
be thought of as 1/12 of the system clock or 1/4 of the system clock. In the "Counter" mode, the
register is incremented on the falling edge of the external input pin, T0 for Timer 0, and T1 for Timer 1.
The T0 and T1 inputs are sampled in every machine cycle at C4. If the sampled value is high in one
machine cycle and low in the next, then a valid high to low transition on the pin is recognized and the
count register is incremented. Since it takes two machine cycles to recognize a negative transition on
the pin, the maximum rate at which counting will take place is 1/8 of the master clock frequency. In
either the "Timer" or "Counter" mode, the count register will be updated at C3. Therefore, in the
"Timer" mode, the recognized negative transition on pin T0 and T1 can cause the count register value
to be updated only in the machine cycle following the one in which the negative edge was detected.
The "Timer" or "Counter" function is selected by the " T C/ " bit in the TMOD Special Function Register.
Each Timer/Counter has one selection bit for its own; bit 2 of TMOD selects the function for
Timer/Counter 0 and bit 6 of TMOD selects the function for Timer/Counter 1. In addition each
Timer/Counter can be set to operate in any one of four possible modes. The mode selection is done
by bits M0 and M1 in the TMOD SFR.
13.1.1 Time-Base Selection
The W79E8213 series can operate like the standard 8051/52 family, counting at the rate of 1/12 of the
clock speed, or in turbo mode, counting at the rate of 1/4 clock speed. The speed is controlled by the
T0M and T1M bits in CKCON, and the default value is zero, which uses the standard 8051/52 speed.
13.1.2 Mode 0
In Mode 0, the timer/counter is a 13-bit counter. The 13-bit counter consists of THx (8 MSB) and the
five lower bits of TLx (5 LSB). The upper three bits of TLx are ignored. The timer/counter is enabled
when TRx is set and either GATE is 0 or
INTx is 1. When T C / is 0, the timer/counter counts clock
cycles; when T C / is 1, it counts falling edges on T0 (P1.2 for Timer 0) or T1 (P0.7 for Timer 1). For
clock cycles, the time base may be 1/12 or 1/4 clock speed, and the falling edge of the clock
increments the counter. When the 13-bit value moves from 1FFFh to 0000h, the timer overflow flag
TFx is set, and an interrupt occurs if enabled. This is illustrated in next figure below.
In “Timer” mode, if output toggled enable bit of P2M1.T0OE or P2M1.T1OE is enable, T0 or T1 output
pin will toggle whenever a timer overflow occurs.
