Preliminary W79E8213/W79E8213R Data Sheet
Publication Release Date: July 11, 2008
- 47 -
Revision A2
INSTRUCTION SET, continued
Op-code HEX
Code
Bytes
W79E8213
series
Machine
Cycle
W79E8213
series
Clock
cycles
8032
Clock
cycles
W79E8213
series vs. 8032
Speed Ratio
CLR
C
C3 1
1 4 12
3
CLR
bit
C2 2
2 8 12
1.5
SETB
C
D3 1
1 4 12
3
SETB
bit
D2 2
2 8 12
1.5
CPL
C
B3 1
1 4 12
3
CPL
bit
B2 2
2 8 12
1.5
ANL C, bit
82
2
2
8
24
3
ANL C, /bit
B0
2
2
6
24
3
ORL C, bit
72
2
2
8
24
3
ORL C, /bit
A0
2
2
6
24
3
MOV C, bit
A2
2
2
8
12
1.5
MOV bit, C
92
2
2
8
24
3
ACALL addr11
71, 91, B1,
11, 31, 51,
D1, F1
2
3 12 24 2
LCALL
addr16 12 3
4 16 24 1.5
RET
22 1
2 8 24
3
RETI
32 1
2 8 24
3
AJMP ADDR11
01, 21, 41,
61, 81, A1,
C1, E1
2
3 12 24 2
LJMP
addr16
02 3
4 16 24 1.5
JMP
@A+DPTR
73 1
2 6 24
3
SJMP
rel
80 2
3 12 24 2
JZ
rel
60 2
3 12 24 2
JNZ
rel
70 2
3 12 24 2
JC
rel
40 2
3 12 24 2
JNC
rel
50 2
3 12 24 2
JB bit, rel
20
3
4
16
24
1.5
JNB bit, rel
30
3
4
16
24
1.5
JBC bit, rel
10
3
4
16
24
1.5
CJNE A, direct, rel
B5
3
4
16
24
1.5
CJNE A, #data, rel
B4
3
4
16
24
1.5
CJNE @R0, #data, rel
B6
3
4
16
24
1.5
CJNE @R1, #data, rel
B7
3
4
16
24
1.5
