Ohaus GT Series Electronic Balance - Manual (Page 69)

30
OPERATION
Statistics Printout Statistics Printout Statistics Printout Statistics Printout Statistics Printout
When statistics is enabled, a printout can be made with any of the major balance
functions such as; Percent, Parts Counting, Check Weighing, Animal Weighing and
FillGuide
TM . Under the Setup Options menu, Statistics has parameters such as
Enable, Standard Deviation, Mean, Sum, High, Low and Difference which can be
turned on or off. Statistics can be printed any time the balance is operational and
statistics is enabled (turned on).
For example, to weigh ten samples and obtain a printout, proceed as follows:
Sampling Sampling Sampling Sampling Sampling
1. .
2. Place the firs t sample on the platform, wait for the stability indicator S S S S S on the
display to show.
3.
appears and the printer outputs
the first sample weight.
4. Remove the first sample.
5. Place the
second sample on the
platform, wait for the stability
indi- cator S S S S S on the display to show.
6.
appears and the printer outputs
the second sample weight.
7. Remove the second sample.
NOTE NOTE NOTE NOTE NOTE: The weight of each sample is
shown on the display and printed.
Maximum sample size = 256.
8. Repeat procedure for as many
samples as required.
9.
to end the sampling procedure.
Printout completes the data.
See sample at right.
Printing Data (Cont.) Printing Data (Cont.) Printing Data (Cont.) Printing Data (Cont.) Printing Data (Cont.)
- - - - - START - - - - -
4/01/95
12:00:00 PM
1 49.54 g
2 49.54 g
3 49.56 g
4 49.57 g
5 50.03 g
6 50.54 g
7 50.04 g
8 50.04 g
9 50.03 g
10 50.04 g
- - - - - - - - - - - - - - - - - - - - -- -
SD Pop.
0.314
Mean 49.893
Sum 498.93
Maximum
50.54
Diff 1.00
Finish 12:05:00 PM
Bal Id 1234
ID 2056853
PR 100012
Name......................................
- - - - - - END - - - - - -
