Ohaus MB45 MOISTURE ANALYZER Manual - Manual (Page 64)

62 MB45
11. Technical Data
11.1 Specifications
Model MB45
Capacity 45g
Readability 0.001g,
0.01%
Results Moisture (%), dry content (%), Wt (g), Wt (custom),
regain, %
Temp. Settings 50°C to 200°C
Drying Programs Standard, fast, ramp, step
Switch-off Criteria Timed, Auto (30, 60, 90 seconds, auto free), manual
Heat Source Halogen
Calibration External calibration mass-20g
Dimensions (DxWxH) (in / cm) 14 x 7.5 x 6 / 35.5 x 19 x 15.2
Pan Size 90 mm. diameter
Adjustable Feet and Level Yes
RS232 Interface Yes
Weight (lb / kg) 9.8 / 4.5
Shipping Weight (lb / kg) 14.1 / 6.4
Admissible ambient conditions
Indoor use only
Altitude:
Up to 2000m
Temperature range: 5 ºC to 40 ºC
Atmospheric humidity: Maximum relative humidity 80% for temperatures up to 31 °C
decreasing linearly to 50% relative humidity at 40 °C.
Warm-up time: At least 60 minutes after connecting the instrument to the
power supply; when switched on from standby-mode, the
instrument is ready for operation immediately.
Voltage fluctuations: Mains supply voltage fluctuations up to –15% +10% of the
nominal range
Over voltage category: II
Pollution degree: 2
Power load: Max. 450 W during drying process
Current consumption: 4 A or 2 A, according to the heating element
Power supply voltage: 100 V – 120 V or 200 V – 240 V, 50/60 Hz
(the voltage is given by the heating element)
Power line fuse: 1 piece, 5 x 20 mm, T6,3 H 250 V
