MB45 37
6.7 Custom units
Custom unit allows the creation of your own custom weighing unit. It permits entering a conversion
factor which the Moisture Analyzer will use to convert grams to the desired unit of measure. The custom
unit is available under the Test Parameters menu, Display settings. When the Moisture Analyzer is
completely set up and running a test, you have the option under the Display to view % Moisture, %
Solids, % Regain, Grams or Custom Unit.
Conversion Factor x Weight in grams = Weight in custom unit
Conversion factors are expressed in scientific notation and entered into the balance in three parts:
1. a number between 0.1 and 1.999999 called the mantissa
2. a power of 10 called the exponent
3. a least significant digit (LSD)
SCIENTIFIC NOTATION EXPONENTS
Number
Between
Conv. 0.1 and Power Man-
Factor 1.999999 of 10 tissa Exp.
123.4 = .1234 x 1000 = .1234 x 10 3
12.34 = .1234 x 100 = .1234 x 10 2
1.234 = .1234 x 10 = .1234 x 10 1
.1234 = .1234 x 1 = .1234 x 10 0
.01234 = .1234 x .1 = .1234 x 10 -1
.001234 = .1234 x .01 = .1234 x 10 -2
.000123 = .123 x .001 = .123 x 10 -3
-3
Moves decimal point 3 places to the left.
-2 Moves decimal point 2 places to the left.
-1 Moves decimal point 1 place to the left.
0 Leaves decimal point in normal position.
1 Moves decimal point 1 place to the right.
2 Moves decimal point 2 places to the right.
3 Moves decimal point 3 places to the right.
TEST PARAMETERS
TEST ID:
PROFILE:
DRY TEMP:
SWITCH OFF:
RESULT:
CUSTOM:
To create a custom unit, proceed as follows:
Press the Test Menu button, EDIT TEST is highlighted.
Press the Enter button, TEST PARAMETERS screen is displayed with
TEST ID highlighted.
TEST ID:
PROFILE:
DRY TEMP:
SWITCH OFF:
RESULT:
CUSTOM:
TEST PARAMETERS Custom unit
Using the down arrow button, scroll to RESULT and press the Enter
button.
Displayed result setting
Using the up/down arrow buttons, select CUSTOM UNITS and press the
Enter button. The screen returns to TEST SETUP.
