GS-4012F/4024 User’s Guide
425
A
P P E N D I X
A
Product Specifications
The following tables summarize the Switch’s hardware and firmware features.
Table 147 Hardware Specifications
SPECIFICATION DESCRIPTION
Dimensions Standard 19” rack mountable
GS-4012F: 438 mm (W) x 225 mm (D) x 44.45 mm (H)
GS-4024: 438 mm (W) x 300 mm (D) x 44.45 mm (H)
Weight GS-4012F: 3.1 Kg
GS-4024: 4.2 Kg
Power Specification One Backup Power Supply (BPS) connector
GS-4012F
AC: 100-240 VAC 50/60 Hz, 1.5 A Max.
DC: -48 VDC ~ -60 VDC, 1.6 A Max.
GS-4024
AC: 100-240 VAC 50/60 Hzx 1.5 A Max.
DC: -48 VDC ~ -60 VDC, 2.2 A Max.
Note: There is no tolerance for the DC input voltage
Interfaces GS-4012F: 8 mini-GBIC (SFP) slots
GS-4024: 20 10/100/1000 Base-Tx ports
All Models: 4 GbE Dual Personality interfaces (Each interface has one
1000Base-T copper port and one Small Form-Factor Pluggable (SFP) fiber
port, with one port active at a time.)
One local management Ethernet port
Auto-negotiation
Auto-MDIX
One console port
Compliant with IEEE 802.3ad/u/x
Back pressure flow control for half duplex
Flow control for full duplex (IEEE 802.3x)
LEDs Per switch: BPS, PWR, SYS, ALM
Per Gigabit Ethernet/mini-GBIC port: 100, 1000/LNK, ACT
Per mini-GBIC port: LNK, ACT
Per Management port: 10, 100
Operating Environment Temperature: 0º C ~ 45º C (32º F ~ 113º F)
Humidity: 10 ~ 90% (non-condensing)
Storage Environment Temperature: -10º C ~ 70º C (13º F ~ 158º F)
Humidity: 10 ~ 90% (non-condensing)
Ground Wire Gauge 18 AWG or larger
