Chapter 20 Queuing Method
GS-4012F/4024 User’s Guide
164
20.2 Configuring Queuing
Click Advanced Application, Queuing Method in the navigation panel.
Figure 78 Queuing Method
The following table describes the labels in this screen.
Table 48 Queuing Method
LABEL DESCRIPTION
Port This label shows the port you are configuring.
Method Select SPQ (Strict Priority Queuing) or WRR (Weighted Round Robin).
Strict Priority Queuing (SPQ) services queues based on priority only. When the
highest priority queue empties, traffic on the next highest-priority queue begins. Q7
has the highest priority and Q0 the lowest.
Weighted Round Robin Scheduling (WRR) services queues on a rotating basis
based on their queue weight (the number you configure in the queue Weight field).
Queues with larger weights get more service than queues with smaller weights.
Q0~Q7 Weight
When you select WRR, enter the queue weight here. Bandwidth is divided across
the different traffic queues according to their weights. Queues with larger weights get
more service than queues with smaller weights.
Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch
loses these changes if it is turned off or loses power, so use the Save link on the top
navigation panel to save your changes to the non-volatile memory when you are
done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
