Chapter 45 Introducing Commands
GS-4012F/4024 User’s Guide
326
• 9600 bps
• No parity
• 8 data bits
• 1 stop bit
• No flow control
45.2.1.1 Initial Screen
When you turn on your Switch, it performs several internal tests as well as line initialization.
You can view the initialization information using the console port. After the initialization, the
login screen displays (refer to
Section 45.3 on page 326 ).
Use the following steps to telnet into your Switch.
1 For local management, connect your computer to the RJ-45 management port (labeled
MGMT) on the Switch.
2 Make sure your computer IP address and the Switch IP address are on the same subnet.
In Windows, click Start (usually in the bottom left corner), Run and then type telnet
192.168.0.1 (the default management IP address) and click OK.
3 A login screen displays (refer to Section 45.3 on page 326 ).
45.3 The Login Screen
After you have successfully established a connection to the Switch using a direct console
connection or Telnet, a login screen displays as shown below. For your first login, enter the
default administrator login username “admin” and password “1234”.
45.4 Command Syntax Conventions
The rules of the commands are listed next.
• The command keywords are in courier new font .
Copyright (c) 1994 - 2007 ZyXEL Communications Corp.
initialize mgmt, ethernet address: 00:13:49:00:00:01
initialize switch, ethernet address: 00:13:49:00:00:02
Initializing switch unit 0...
Initializing MSTP.............
Initializing VLAN Database...
Initializing IP Interface...
Initializing Advanced Applications...
Initializing Command Line Interface...
Initializing Web Interface...
Press ENTER to continue...
Enter User Name : admin
Enter Password : XXXX
