Chapter 34 VRRP

GS-4012F/4024 User’s Guide

269

34.3 VRRP Configuration

The following sections describe the different parts of the VRRP Configuration screen.

34.3.1 IP Interface Setup

Before configuring VRRP, first create an IP interface (or routing domain) in the IP Setup
screen (see the

Section 7.6 on page 83

for more information).

Click IP Application, VRRP and click the Configuration link to display the VRRP
Configuration screen as shown next.

"

You can only configure VRRP on interfaces with unique VLAN IDs.

"

Routing domains with the same VLAN ID are not displayed in the table
indicated.

Figure 154 VRRP Configuration: IP Interface

The following table describes the labels in this screen.
