Figure 166 wall-mounting example – ZyXEL Communications NBG420N User Manual
Page 277
Appendix A Product Specifications and Wall-Mounting Instructions
NBG420N User’s Guide
277
1
Be careful to avoid damaging pipes or cables located inside the wall when
drilling holes for the screws.
3 Do not screw the screws all the way into the wall. Leave a small gap of about 0.5 cm
between the heads of the screws and the wall.
4 Make sure the screws are snugly fastened to the wall. They need to hold the weight of
the NBG420N with the connection cables.
5 Align the holes on the back of the NBG420N with the screws on the wall. Hang the
NBG420N on the screws.
Figure 166 Wall-mounting Example
The following are dimensions of an M4 tap screw and masonry plug used for wall mounting.
All measurements are in millimeters (mm).
