Chapter 7 Wireless LAN
NBG420N User’s Guide
114
Figure 76 Port Forwarding
The following table describes the labels in this screen.
7.11 Accessing the iPod Touch Web Configurator
To access the iPod Touch web configurator through your iPod Touch you must first connect it
to the NBG420N’s wireless network. Follow the steps below to do this.
Table 42 Port Forwarding
LABEL DESCRIPTION
# This is the number of an individual port forwarding entry.
Rule This column displays the configured port forwarding rules. To configure a new rule
you must use the web configurator from your computer.
Port This column displays the port number(s) which are forwarded when the rule is
turned on.
Status Use this column to manage the status of the rules. Press the left side of the button
to turn the rule ON and press the right side of the button to turn the rule OFF.
