Appendix A Product Specifications and Wall-Mounting Instructions
NBG420N User’s Guide
276
The following list, which is not exhaustive, illustrates the standards supported in the
NBG420N.
Wall-mounting Instructions
Do the following to hang your NBG420N on a wall.
"
See the
for the size of screws to use and how far
apart to place them.
1 Locate a high position on a wall that is free of obstructions. Use a sturdy wall.
2 Drill two holes for the screws. Make sure the distance between the centers of the holes
matches what is listed in the product specifications appendix.
Table 116 Standards Supported
STANDARD
DESCRIPTION
RFC 867
Daytime Protocol
RFC 868
Time Protocol.
RFC 1058
RIP-1 (Routing Information Protocol)
RFC 1112
IGMP v1
RFC 1305
Network Time Protocol (NTP version 3)
RFC 1631
IP Network Address Translator (NAT)
RFC 1723
RIP-2 (Routing Information Protocol)
RFC 2236
Internet Group Management Protocol, Version 2.
RFC 2516
A Method for Transmitting PPP Over Ethernet (PPPoE)
RFC 2766
Network Address Translation - Protocol
IEEE 802.11
Also known by the brand Wi-Fi, denotes a set of Wireless LAN/WLAN
standards developed by working group 11 of the IEEE LAN/MAN
Standards Committee (IEEE 802).
IEEE 802.11b
Uses the 2.4 gigahertz (GHz) band
IEEE 802.11g
Uses the 2.4 gigahertz (GHz) band
IEEE 802.11n
IEEE 802.11d
Standard for Local and Metropolitan Area Networks: Media Access
Control (MAC) Bridges
IEEE 802.11x
Port Based Network Access Control.
IEEE 802.11e QoS
IEEE 802.11 e Wireless LAN for Quality of Service
Microsoft PPTP
MS PPTP (Microsoft's implementation of Point to Point Tunneling
Protocol)
MBM v2
Media Bandwidth Management v2
