Chapter 7 Wireless LAN
NBG420N User’s Guide
111
Figure 74 System Status screen
The following table describes the labels in this screen.
Table 41 System Status screen
LABEL DESCRIPTION
Logout Press this to logout of the iPod Touch web configurator.
LAN
IP Address This field displays the NBG420N’s LAN (Local Area Network) IP address.
WAN
IP Address This field displays the NBG420N’s WAN IP address. If this field displays “-” it
means the WAN is not connected. Try pressing Reconnect if your WAN
connection is not working.
Reconnect Press Reconnect to renew your NBG420N’s WAN connection.
WLAN
Name (SSID) This field displays the SSID (Service set identifier) of the NBG420N’s Wireless
LAN.
Security Mode This field displays the security authentication mode of the NBG420N’s Wireless
LAN. This can be No Security, WPA-PSK, WPA2-PSK or WEP.
