Chapter 7 Wireless LAN
NBG420N User’s Guide
109
1 Make sure the Wireless LAN on the NBG420N is enabled and that you know the
security settings (if any). To do this check the Wireless LAN > General screen in the
web configurator from your computer.
2 On the iPod Touch’s main screen press Settings > Wi-fi and from the list press the
NBG420N’s network name (SSID) to connect to it. If you are prompted for any security
settings enter them and press connect. If you cannot connect check your security settings
in the web configurator from your computer and try again.
3 After connecting to the NBG420N’s wireless LAN network launch the iPod Touch
Internet browser and enter the NBG420N’s IP address (default: 192.168.1.1) into the
address bar. The login screen displays.
7.10.1 Login Screen
After accessing the NBG420N’s IP address in the iPod Touch web browser the screen below
will display.
"
You cannot change your password in the iPod Touch web configurator. To
change your password log into the web configurator using your computer.
Figure 73 Login Screen
The following table describes the labels in this screen.
Table 40 Login Screen
LABEL DESCRIPTION
Auto Login Select this checkbox to automatically log into the iPod Touch web configurator
when accessing it through the same iPod Touch device.
Password Enter the password for the NBG420N. If you haven’t changed the default
password earlier this is “1234”.
Login Press the Login button to log into the iPod Touch web configurator.
Reset Press the Reset button to clear your selections and start over.
