Chapter 9 LAN
NBG420N User’s Guide
130
9.3 LAN IP Screen
Use this screen to change your basic LAN settings. Click Network > LAN.
Figure 83 Network > LAN > IP
The following table describes the labels in this screen.
9.4 LAN IP Alias
IP alias allows you to partition a physical network into different logical networks over the
same Ethernet interface. The NBG420N supports three logical LAN interfaces via its single
physical Ethernet interface with the NBG420N itself as the gateway for each LAN network.
To change your NBG420N’s IP alias settings, click Network > LAN > IP Alias. The screen
appears as shown.
Table 47 Network > LAN > IP
LABEL DESCRIPTION
LAN TCP/IP
IP Address Type the IP address of your NBG420N in dotted decimal notation 192.168.1.1
(factory default).
IP Subnet Mask The subnet mask specifies the network number portion of an IP address. Your
NBG420N will automatically calculate the subnet mask based on the IP address
that you assign. Unless you are implementing subnetting, use the subnet mask
computed by the NBG420N.
Apply Click Apply to save your changes back to the NBG420N.
Reset Click Reset to begin configuring this screen afresh.
