Dimension ES-2024 Ethernet Switch
Mirroring 13-3
Table 13-1 Mirroring
LABEL DESCRIPTION
Direction Select which direction of traffic you want to copy from the mirrored port(s) to the monitor port.
Select Ingress to copy the traffic coming into the switch through the mirrored port(s).
Select Egress to copy the traffic going out of the switch through the mirrored port(s).
Select Both to copy the traffic coming into or going out of the switch through the mirrored port(s).
Port A mirrored port is a port from which you copy the traffic to the monitor port. Do this to examine the
mirrored port’s traffic in more detail without interfering with the traffic flow on the mirrored port.
Select the Mirrored check box for each port from which you want to copy traffic.
You can select more than one mirrored port.
Apply Click Apply to save the changes.
Cancel Click Cancel to start configuring the screen again.
