Dimension ES-2024 Ethernet Switch
27-6 IEEE 802.1Q Tagged VLAN
Figure 27-9 vlan1q port accept Command Example
27.4.9 vlan1q port gvrp
Syntax:
sys sw vlan1q port gvrp
where
= A port number
= Turn GVRP on or off.
This command turns GVRP on or off for the specified port.
The following example turns off GVRP for port 2.
Figure 27-10 vlan1q port gvrp Command Example
27.4.10 vlan1q svlan cpu
Syntax:
sys sw vlan1q svlan cpu
where
= The VLAN ID. Valid parameter range = [1 – 2048].
This command sets the management VLAN (CPU). You can only use ports that are members of this management
VLAN in order to manage the switch.
The following example sets VLAN ID 2 to be the CPU (management) VLAN.
Figure 27-11 vlan1q svlan cpu Command Example
27.4.11 vlan1q svlan setentry
Syntax:
ES-2024> sys sw vlan1q port accept 2 tagged
ES-2024> sys sw vlan1q port gvrp 2 disable
ES-2024> sys sw vlan1q svlan cpu 2
