Dimension ES-2024 Ethernet Switch
22-6 Cluster Management
Table 22-4 Configuring Cluster Management
LABEL DESCRIPTION
Apply Click Apply to save these changes to the switch.
Cancel Click Cancel to begin configuring this part of the screen afresh.
Clustering
Candidate The following fields relate to the switches that are potential cluster members.
List A list of suitable candidates found by auto-discovery is shown here. The switches must be
directly connected. Directly connected switches that are set to be cluster managers will not be
visible in the Clustering Candidate list. Switches that are not in the same management
VLAN group will not be visible in the Clustering Candidate list.
Password Each cluster member’s password is its web configurator password. Select a member in the
Clustering Candidate list and then enter its web configurator password. If that switch
administrator changes the web configurator password afterwards, then it cannot be managed
from the Cluster Manager. Its Status is displayed as Error in the Cluster Management
Status screen and a warning icon (
) appears in the member summary list below.
If multiple devices have the same password then hold [SHIFT] and click those switches to
select them. Then enter their common web configurator password.
Apply Click Apply to save these changes to the switch.
Cancel Click Cancel to begin configuring this part of the screen afresh.
Refresh Click Refresh to perform auto-discovery again to list potential cluster members.
The next summary table shows the devices selected for clustering.
Index This is the index number of a cluster member switch.
MacAddr This is the cluster member switch’s hardware MAC address.
Name This is the cluster member switch’s System Name.
Model This is the cluster member switch’s model name.
Remove Select this checkbox and then click the Remove button to remove a cluster member switch
from the cluster.
Cancel Click Cancel to begin configuring this part of the screen afresh.
