Dimension ES-2024 Ethernet Switch
7-4 VLAN
Table 7-2 802.1Q VLAN Status
LABEL DESCRIPTION
VID VID is the PVID, the Port VLAN ID assigned to untagged frames or priority-tagged frames
received on this port that you configure in the VLAN Port Setting screen.
Port Number This column displays the ports that are participating in a VLAN. A tagged port is marked as T,
an untagged port is marked as U and ports not participating in a VLAN in marked as “–“.
Elapsed Time This field shows how long it has been since a normal VLAN was registered or a static VLAN
was set up.
Status This field shows how this VLAN was added to the switch; dynamically using GVRP or
statically, that is, added as a permanent entry.
Poll Interval(s) The text box displays how often (in seconds) this screen refreshes. You may change the
refresh interval by typing a new number in the text box and then clicking Set Interval.
Stop Click Stop to halt polling statistics.
Previous/Next Page Click one of these buttons to show the previous/next screen if all status information cannot be
seen in one screen.
7.2.1 802.1Q VLAN Port Settings
To configure the 802.1Q VLAN settings on a port, click the VLAN Port Setting link in the VLAN Status screen.
