Dimension ES-2024 Ethernet Switch
IEEE 802.1Q Tagged VLAN 27-3
Figure 27-3 Deleting Default VLAN Example
27.4 IEEE VLAN1Q Tagged VLAN Configuration Commands
These sw (switch) commands allow you to configure and monitor the IEEE 802.1Q Tagged VLAN.
27.4.1 garp status
Syntax:
sys sw garp status
This command shows the switch’s GARP timer settings, including the join, leave and leave all timers.
An example is shown next.
Figure 27-4 GARP STATUS Command Example
27.4.2 garp timer
Syntax:
sys sw garp timer timer
where
= This sets the duration of the Join Period timer for GVRP in
milliseconds. Each port has a Join Period timer. The allowed
Join Time range is between 100 and 32767 milliseconds; the
default is 200 milliseconds.
= This sets the duration of the Leave Period timer for GVRP in
milliseconds. Each port has a single Leave Period timer. Leave
Time must be two times larger than Join Timer; the default is
600 milliseconds.
= This sets the duration of the Leave All Period timer for GVRP
in milliseconds. Each port has a single Leave All Period timer.
Leave All Timer must be larger than Leave Timer; the default
is 10000 milliseconds.
ES-2024> sys sw vlan1q svlan cpu 3
ES-2024> sys sw vlan1q svlan delentry 1
ES-2024> sys sw garp status
GARP Timer Status :
Join Timer = 200 msec
Leave Timer = 600 msec
Leave All Timer = 10000 msec
ES-2024>
