Dimension ES-2024 Ethernet Switch
27-8 IEEE 802.1Q Tagged VLAN
Step 2. The switch checks the PVID table and assigns a temporary VID of 1.
Step 3. The switch ignores the port from which the frame came, because the switch does not send a frame to the
port from which it came. The switch also does not forward frames to “forbidden” ports.
Step 4. If after looking at the SVLAN, the switch does not have any ports to which it will send the frame, it
won’t check the port filter.
27.4.12 vlan1q svlan delentry
Syntax:
sys sw vlan1q svlan delentry
where
= The VLAN ID [1 – 2048].
This command deletes the specified VLAN ID entry from the static VLAN table
The following example deletes entry 2 in the static VLAN table.
Figure 27-13 vlan1q svlan delentry Command Example
27.5 vlan1q svlan active
Syntax:
sys sw vlan1q svlan active
This command enables the specified VLAN ID in the SVLAN (Static VLAN) table.
27.6 vlan1q svlan inactive
Syntax:
sys sw vlan1q svlan inactive
This command disables the specified VLAN ID in the SVLAN (Static VLAN) table.
27.7 vlan1q svlan list
Syntax:
sys sw vlan1q svlan list
This command shows the IEEE 802.1Q Tagged SVLAN (Static VLAN) table.
An example is shown next.
For the AdCtl section of the last column, “-“ is a port set to normal, “x” is a forbidden port and “F” is a fixed port.
ES-2024> sys sw vlan1q svlan delentry 2
