Dimension ES-2024 Ethernet Switch
27-2
IEEE 802.1Q Tagged VLAN
The following procedure shows you how to configure tagged VLAN.
Step 1.
Use the IEEE 802.1Q tagged VLAN commands to configure tagged VLAN for the switch.
• Use the
sys sw vlan1q svlan setentry
command to configure a VLAN ID for each port on the
switch.
• Use the
sys sw vlan1q svlan active
command when you are finished configuring the VLAN (see
the last step).
• Use the
sys sw vlan1q port defaultVID command
to set the VLAN ID you created for a port to
that specific port in the PVID table.
• Use the
sys sw vlan1q svlan active
command to activate the VLAN IDs.
Example:
Figure 27-1 Tagged VLAN Configuration and Activation Example
Step 2.
Configure your management VLAN.
• Use the
sys sw vlan1q svlan setentry
command to configure a VLAN ID (VID 3 in this example)
for managing the switch (the “management” or “CPU” VLAN).
• Use the
sys sw vlan1q svlan active
command to activate the new management VLAN ID.
Example:
Figure 27-2 CPU VLAN Configuration and Activation Example
Step 3.
Perform the procedure below to complete the VLAN setup.
a. Telnet to the operational IP address of the switch.
b. Use
the
sys sw vlan1q svlan cpu
command to set VID 3 as the management VLAN.
c. Use
the
sys sw svlan delentry
command to remove the default VLAN ID (1).
Example:
ES-2024> sys sw vlan1q svlan setentry example 3 24 fixed tag
ES-2024> sys sw vlan1q svlan active 3
ES-2024> sys sw vlan1q svlan setentry up1 2000 24 fixed tag
for newly create VLAN, please use svlan active
ES-2024> sys sw vlan1q port defaultVID 24 2000
ES-2024> sys sw vlan1q svlan setentry up1 2001 25 fixed untag
for newly create VLAN, please use svlan active
ES-2024> sys sw vlan1q port defaultVID 25 2001
ES-2024> sys sw vlan1q svlan active 2000
ES-2024> sys sw vlan1q svlan active 2001
